3M™ Nextel™ 720 Woven Fabrics EF-19
High Temperature Mullite Ceramic Fiber Fabric
3M™ Nextel™ 720 Woven Fabrics EF-19 are advanced ceramic fiber textiles designed for extreme high-temperature environments where superior thermal stability, oxidation resistance, and mechanical durability are required.
Manufactured under the high-performance Nextel ceramic fiber family, EF-19 woven fabrics are widely used in aerospace thermal protection systems, turbine engine insulation, ceramic matrix composites (CMC), and high-temperature industrial applications.
These fabrics are woven using Nextel 720 continuous filament yarn, composed primarily of mullite ceramic fibers consisting of approximately 85% alumina (Al2O3) and 15% silica (SiO2).
This mullite composition provides excellent creep resistance, superior long-term thermal stability, and high resistance to oxidation in extreme temperatures, making EF-19 fabrics ideal for aerospace heat shields, thermal barriers, and high-temperature structural composite reinforcement.
With continuous operating capability up to 1200–1400°C, these fabrics are engineered for critical aerospace, defense, and industrial environments where conventional materials cannot perform effectively.
Product Overview
Nextel 720 EF-19 woven fabrics provide excellent structural integrity and long-term thermal durability in extreme heat environments.
The woven ceramic textile construction ensures high dimensional stability, mechanical strength, and compatibility with ceramic matrix composite manufacturing processes.
Compared with Nextel 312 and Nextel 440 fabrics, Nextel 720 fabrics offer improved creep resistance and better long-term performance at high temperatures, making them ideal for advanced aerospace insulation and structural ceramic composite applications.
Key Features
- Mullite-based ceramic fiber composition (Alumina–Silica)
- Excellent long-term thermal stability
- Continuous operating temperature up to 1200–1400°C
- Superior oxidation and chemical resistance
- Outstanding creep resistance at high temperatures
- Non-combustible and flame resistant
- Suitable for ceramic matrix composite reinforcement
Technical Properties of Nextel 720 EF-19
| Property | Typical Value |
|---|---|
| Material | Nextel 720 Ceramic Fiber |
| Fiber Composition | Mullite (~85% Al2O3 / ~15% SiO2) |
| Fabric Construction | Woven Fabric |
| Fabric Style | EF-19 |
| Weave Type | Plain Weave |
| Operating Temperature | ~1200 – 1400°C |
| Fiber Density | ~3.4 g/cm³ |
| Filament Diameter | ~10 – 12 µm |
| Fabric Thickness | ~0.45 – 0.65 mm |
| Color | White / Off-White |
Values are typical and may vary depending on fabric construction and manufacturing specifications.
Typical Applications
- Aerospace thermal protection systems (TPS)
- Ceramic matrix composite reinforcement
- Aircraft and spacecraft heat shield systems
- Gas turbine engine insulation
- High-temperature industrial furnace insulation
- Rocket propulsion thermal protection systems
- Structural ceramic composite components
Advantages of Using Nextel 720 EF-19
- Excellent creep resistance during long-term exposure
- Superior thermal stability in extreme heat environments
- Outstanding oxidation resistance
- Reliable performance in aerospace and turbine applications
- Ideal reinforcement for advanced ceramic matrix composites
